| Total Measurement Range: |
-148° to 32°F (-100° to 0°C); +/- 5.4°F (+/- 3°C) |
| Optimal Measurement Range: |
-112 to -22°F (-80 to -30°C); +/-3.6°F (+/- 2°C) |
| Operating Temperature: |
-40 to 140°F (-40 to 60°C) |
| Operating Pressure Range: |
0 to 725 psi (0-50 bar) |
| Operating Humidity: |
Non-condensing |
| Analog Outputs: |
4 – 20mA
0 – 20mA
0 – 10 V |
| Output Units |
Dew Point/Frost Point, ppm & ppb (by volume), ppm (by weight) |
| Sensor Threads: |
NPT 1/2″ |
| Sensor Housing: |
IP65 – NEMA4 (AISI316L) |
| Display Housing: |
IP40 |
| Display Weight: |
385g |
| Power: |
Rechargeable lithium-ion battery or 45 W USB-C AC adapter |
| Battery Recharging Time: |
Approximately 2 Hours |
| Battery Charger Input Requirements: |
110-240VAC / 50-60Hz / 1.2A |
| Run Time on Battery Power: |
10 Hours- Continuous Use / Up to 30 days- Data logging only |
| Languages Supported: |
Ten possible languages (See manual for details) |
| Data Logging Capacity: |
Up to 5.5 million real-time data values |
| Data Logging Interval Options: |
1s, 5s, 15s, 30s, 1min, 5min, 15min, 30min, 1h, 3h, 12h |
| Logging Duration Options: |
1min, 5min, 15min, 30min, 1h, 3h, 12h, 24h, 7d, 31d, Memory Full |
| Available Display Units:
(Between 1 and 3 can be
displayed at one time) |
Dew Point Temperature (°F or °C)
PPB (Parts Per Billion Water – by volume)
PPM (Parts Per Million Water – by volume)
PPMW (Parts Per Million Water – by weight) |
